12V DC 775 Motor with Drill Chuck & Mounting Bracket – High Speed | High Torque | DIY Drilling Polishing Cutting Machine

12V DC 775 Motor with B10 Drill Chuck & Mounting Bracket

Power up your DIY projects with this high-performance 12V DC 775 Motor
combo, complete with a B10 drill chuck and sturdy mounting bracket.
Designed for makers, hobbyists, and professionals, this motor delivers
high torque, low noise, and long-lasting performance for drilling,
polishing, cutting, and more.

⚙️ MOTOR SPECIFICATIONS:

- Rated Voltage: DC 12V
- No-Load Speed: 10,000 RPM (12V)
- Load Speed: 8,800 RPM
- Starting Current: 4–5A
- Power: 100W–200W
- Motor Body Diameter: 42mm
- Motor Body Length: 66.5mm
- Shaft Diameter: 5mm
- Shaft Length: 16mm
- Commutation: Brush Type
- Built-in Cooling Fan
- Double Ball Bearing for smooth operation

🔩 DRILL CHUCK SPECIFICATIONS:

- Chuck Type: B10 / JT0 Drill Chuck
- Clamping Range: 0.3mm – 6mm drill bits
- Material: High-quality metal
- Compatible Shaft: 5mm motor shaft

🗜️ MOUNTING BRACKET SPECIFICATIONS:

- Length: 50mm | Width: 52mm | Height: 53mm
- Mounting Hole Diameter: 4mm
- Bracket Thickness: 3mm
- Material: Durable metal

✅ KEY FEATURES:

- Pure copper coil – low heat, high efficiency
- High-performance magnet for increased torque
- Built-in cooling fan for continuous operation
- Low noise, high-speed operation
- Ball bearing construction for durability
- Long service life with minimal maintenance
- Easy to mount and install
- Breadboard and DIY project friendly

🛠️ APPLICATIONS:

- PCB drilling
- Wood & plastic cutting
- Polishing & grinding
- Mini lathe press
- Small table saw attachment
- Model making
- Jewelry crafting
- DIY CNC machines
- RC hobby projects

⚡ POWER SUPPLY:

- Input: DC 12V (also supports up to 24V)
- Recommended: 12V 2A–5A power adapter or battery

📦 PACKAGE INCLUDES:

- 1 x 775 DC Motor (12V)
- 1 x B10 Drill Chuck
- 1 x Mounting Bracket
- 1 x Chuck Key / Wrench
- 2 x M3 Screws
- 1 x Detachable Connecting Link

⚠️ NOTE:
Do NOT connect to AC mains power (110V/220V).
Use DC 12V power supply only.
Drill bits and power supply are NOT included unless stated.
